| NO. | Item | Contents | Unit |
| 1 | LCD Size | 6.86 inch(Diagonal) | – |
| 2 | Display Mode | Normally Black | – |
| 3 | Resolution | 480(H)RGBx1280(V) | – |
| 4 | Dot pitch | 0.1254(H)×0.1254(V)mm | – |
| 5 | Active area | 60.19(H)x160.51(V)mm | – |
| 6 | Module size | 66.41(H)x174.19(V)x4.5(D)mm | |
| 7 | Color arrangement | RGB Vtertical stripe | – |
| 8 | Interface | MIPI-4L | |
| 9 | Luminance(cd/m2) | TBD | |
| 10 | Viewing Direction | ALL | |
| 11 | Backlight | 9 White LED | |
| 12 | Operating Temp. | -20℃~+70℃ | ℃ |
| 13 | Storage Temp. | -30℃~+80℃ | ℃ |
