Specializing in TFT LCD and Capacitive Touch Screens.
| NO. | Item | Contents |
| 1 | LCD Size | 5.0 inch(Diagonal) |
| 2 | Display Mode | Normally Black |
| 3 | Resolution | 800(H)RGB×480(V) |
| 4 | Dot pitch | 0.135(H)×0.135(V)mm |
| 5 | Active area | 108.0(H)×64.8(V)mm |
| 6 | Module size | 120.7(H)x75.8(V)x2.9(D)mm |
| 7 | Color arrangement | RGB Vtertical stripe |
| 8 | Interface | RGB24BIT |
| 9 | Backlight | 12White LED |
| 10 | Operating Temp. | -20℃~+70℃ |
| 11 | Storage Temp. | -30℃~+80℃ |
