Specializing in TFT LCD and Capacitive Touch Screens.
| NO. | Item | Contents | |
| 1 | LCD Size | 5.0 inch(Diagonal) | |
| 2 | Display Mode | Normally Black | |
| 3 | Resolution | 800(H)RGB×480(V) | |
| 4 | Dot pitch | 0.135(H)×0.135(V)mm | |
| 5 | Active area | 108.0(H)x 64.8(V)mm | |
| 6 | Module size | 120.7(H)×75.8(V)x2.9(D)mm | |
| 7 | Color arrangement | RGB Vtertical stripe | |
| 8 | Interface | RGB24BIT | |
| 9 | Drive IC | – | |
| 10 | Luminance(cd/m2) | TBD | |
| 11 | Viewing Direction | ALL | |
| 12 | Backlight | 12White LED | |
| 13 | Operating Temp. | -20℃~+70℃ | |
| 14 | Storage Temp. | -30℃~+80℃ | |
| 15 | Weight | TBD | |
