Specializing in TFT LCD and Capacitive Touch Screens.
| Item | Standard Value | Unit | ||||||
| LCD Type | Transmissive TFT,262K color | — | ||||||
| Number of Dots | 480(RGB)X360 | — | ||||||
| Viewing Direction | ALL | o’clock | ||||||
| LCM Outline Dimension | 46.00(W)X40.80(H)X2.0(T) | mm | ||||||
| Viewing area | 41.80(W)X31.60(H) | mm | ||||||
| Active area | 40.824(W)X30.618(H) | mm | ||||||
| Operating temperature | -20℃~70℃ | — | ||||||
| Storage temperature | -30℃~80℃ | — | ||||||
| Driving IC | ST7701S | — | ||||||
| Approx.weight | TBD | g | ||||||
